Descrizione completa
Mechanical Dimensions 203 x 76 x 33 mm (8 x 3 x 1.3") Weight Device: 320 g (11.3 oz) Wall mount: 45 g (1.6 oz) 210W adapter: 770 g (1.7 lb) Enclosure material Polycarbonate Hardware Management interface Ethernet In-Band Networking interface (8) GbE RJ45 ports PoE interface (7) PoE/PoE+ (Pins 1, 2+ 3, 6-) (1) PoE++ (Pair A 1, 2+ 3, 6-) (Pair B 4, 5+ 7, 8-) Total non-blocking throughput 8 Gbps Switching capacity 16 Gbps Power method (1) 54V, 3.9A power adapter (Included) PoE++ (Pins 1, 2+ 3, 6- and 4, 5+ 7, 8-) Power supply 54V, external, 3.9A/210W Supported voltage range 44—57V DC Max. power consumption 9W with PoE input (Excluding PoE output) 8W with AC adapter input (Excluding PoE output) Total available PoE PoE++ input: 42W PoE+ input: 16W 60W PoE adapter input: 42W 60W AC adapter input: 52W 210W AC adapter input: 202W* *At 45° C (113° F) operating temperature. Reduced to 161W (230V) or 121W (115V) at 60° C (140° F) Max. PoE+ wattage per port by PSE 30W Button Factory reset Ambient operating temperature PoE++ input: -30 to 60° C (-22 to 140° F) 60W AC adapter input: -20 to 45° C (-4 to 113° F) 210W AC adapter input: -20 to 60° C (-4 to 140° F) Ambient operating humidity 10 to 90% noncondensing Certifications CE, FCC, IC Switching Features Layer 2 features Port isolation Storm control Port mirroring Multicast / broadcast rate limiting Flow control Jumbo frames Egress rate limit Layer 3 features – LEDs System Status Ethernet PoE Link/activity Application Requirements UniFi Network Version 8.0.7 and later
