Mechanical Dimensions Ø220 x 48.1 mm (Ø8.66 x 1.89") Weight Without mount: 960 g (2.1 lb) With mount: 1090 g (2.4 lb) Enclosure materials Top housing: plastic Bottom housing: aluminum Mount material SGCC steel Hardware Management interface Ethernet Bluetooth Networking interface (1) 2.5GbE RJ45 port Button Reboot and factory-reset LED W/B Power method PoE+ Power supply UniFi PoE switch 48V, 0.5A PoE adapter (optional) Supported voltage range 44 - 57VDC Max. power consumption 22W Max. TX power 2.4 GHz 5-7 GHz 22 dBm 26 dBm MIMO 2.4 GHz 5 GHz 6 GHz 2 x 2 (UL MU-MIMO) 4 x 4 (DL/UL MU-MIMO) 4 x 4 (DL/UL MU-MIMO) Throughput rate 2.4 GHz 5 GHz 6 GHz 573.5 Mbps 4.8 Gbps 4.8 Gbps Antenna gain 2.4 GHz 5 GHz 6 GHz 3.2 dBi 5.3 dBi 6 dBi Mounting Wall/ceiling (included) Operating temperature -30 to 60° C (-22 to 140° F) Operating humidity 5 - 95% noncondensing Certifications CE, FCC, IC Software WiFi standards 802.11a/b/g WiFi 4/WiFi 5/WiFi 6/WiFi 6E Wireless security WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3) BSSID 8 per radio VLAN 802.1Q Advanced QoS Per-user rate limiting Guest traffic isolation Supported Concurrent clients 600+ Zero wait DFS Yes Supported Data Rates (Mbps) 802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11b 1, 2, 5.5, 11 Mbps 802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11n (WiFi 4) 6.5 Mbps to 600 Mbps (MCS0 - MCS31, HT 20/40) 802.11ac (WiFi 5) 6.5 Mbps to 3.4 Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80/160) 802.11ax (WiFi 6/6E) 7.3 Mbps to 4.8 Gbps (MCS0 - MCS11 NSS1/2/3/4, HE 20/40/80/160)
